Fender American Jazzmaster Left Handed Vintage Wiring Harness

Description

Fender American Jazzmaster Left Handed Vintage Wiring Harness

This pre-wired Fender American Jazzmaster Left Handed Vintage Wiring Harness is designed for replacing old electrics or upgrading the electronics of imported models or for use on DIY Kits. We take a massive amount of care and attention when putting our Fender American Jazzmaster Left Handed harnesses together. Everything is fully tested before being posted to you.

This is a Professional American Jazzmaster Left Handed Wring Harness using the very best in components to enhance the quality of tone and sound output from your guitar.

Components
USA 500k CTS Potentiometers x 2, Left Handed / Reverse Taper Split Shaft.
Sprague Orange Drop Capacitor x 1, Size 0.022uF.
Switchcraft USA Right Angle Toggle 3 Way Switch.
Switchcraft USA Jack Socket.
Tinned Copper “Buss” Ground Wire.
Gavitt USA Cloth Covered 22AWG Wire.
Mounted on a 3D Printed Wiring Template.
Jack Socket and Pots Supplied with Nut, Flat Washer & Locking Star Washer.
You are welcome to Contact Us with your custom requirements.

Controls
Master Volume.
Master Tone.

Switching
Position 1 – Bridge Pickup.
Position 2 – Bridge & Neck Pickup.
Position 3 – Neck Pickup.

Will this fit my guitar?
Our pre-wired Fender American Jazzmaster Left Handed Vintage Wiring Harness is wired to fit genuine Fender models. If installing into an imported model / DIY guitar kit you will need to ensure the Potentiometer holes will take CTS pots (approx 10mm). This can be done using a round file or carefully with a 10mm drill.

Centre to centre measurements between components
Centre of volume to tone pot – 55mm.
Centre of jack socket to tone pot – 60mm.
Centre of switch to volume pot – 120mm.
Measurements can sometimes vary slightly on some American Jazzmaster Left Handed models, so we allow plenty of movement in wire lengths between components to allow for a comfortable fit.
If your measurements are different from the above, please let us know and we will build your harness to your specifications.

Installation, Wiring Diagram and Support
Please see our Support Page for wiring diagrams and fitting instructions.
We have made it as simple as possible to install your Fender American Jazzmaster Left Handed Vintage Wiring Harness with a fitting guide and simple to follow wiring diagram.

We also offer full support should you need it.

Order Times
We make everything to order and the turnaround time for a Fender American Jazzmaster Left Handed Vintage Wiring Harness is 2-3 days.
